Razor Coil Fencing
Single coil razor Fencing is made with stainless steel sheet and wire AISI 304 or good quality carbon steel sheets.
Single coil razor wire in stainless steel offers longer service life compared with other materials, and much better property of corrosion resistance. This kind of razor wire is supplied in straight ribbons or single coil concertina forms.
Single coil razor wire is available with a variety of blade styles: BT-10, BT-12, BT-18, BT-22, BT-28, BT-30, BT-60, etc. The blade length, spacing and width can be produced according to your specific requirements.
Material:
Stainless steel razor barbed wire, Hot-dipped galvanized razor barbed wire (we can make a higher zinc with the razor wire )
We can provide to clients to Hop-dipped galvanized razor wire coil with stainless steel clip or hot-dipped galvanized steel clip.Also can be requied by clients.
Razor Barbed Tape Wire Kindly refer to below technical information of our products and contact us with your detail requirements. Razor Blade Specification: |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Barbed Tape Concertina (CBT);Barbed Tape Obstacle (BTO)
Standard materials are either galvanized or stainless steel.
Standard packages products are shown in the tables above, special specifications available on request.
Barbed Tape Wire Specification |
||||
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Type |
Notes |
450mm |
33 |
7-8M |
CBT-60.65 |
Single coil |
500mm |
56 |
12-13M |
CBT-60.65 |
Single coil |
700mm |
56 |
13-14M |
CBT-60.65 |
Single coil |
960mm |
56 |
14-15M |
CBT-60.65 |
Single coil |
450mm |
56 |
8-9M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
500mm |
56 |
9-10M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
600mm |
56 |
10-11M (3 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
600mm |
56 |
8-10M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
700mm |
56 |
10-12M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
800mm |
56 |
11-13M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
900mm |
56 |
12-14M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
960mm |
56 |
13-15M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
980mm |
56 |
14-16M (5 CLIPS) |
BTO-10.12.18.22.28.30 |
Cross type |
358 Mesh High Security Fence Combined with Razor Wire Coils Fencing
Why is 358 mesh called Anti-Climb Fence?
358 security fence is made of rectangular opening welded mesh with finger proof aperture. The 358 mesh has an opening of 3 inch in length, 0.5 inch in height and the wire gauge applied is BWG 8. 358 Mesh gets its name from above numbers (3, 0.5 and 8) applied for designing this welded mesh. Calculated in millimeter, the size of the weld wire mesh opening will be 76.2mm in length x 12.7mm in height x 4mm (wire diameter).
From above data, 358 mesh is a strong security screen combined with a thick wire diameter of 4mm, and a small opening in height. This design provides a barrier that is difficult to climb or penetrate. The closely arranged wires are welded to form an anti-climbing mesh panels. The hole height is only 12.7mm which is totally impossible for fingers to catch and difficult for tools to conduct holding or cut. Almost impossible to cut wires by use of conventional bolt or wire cutters. With the anti-climbing and anti-cutting and finger-proof features, 358 mesh makes ideal security fencings for bridge guarding, prison security fencing, electrical sub-station fencing, gas pipeline security fence as well as safety barrier for those sites and facilities of public health and public safety. The security level can be enhanced with using of razor wire concertina spirals on the 358 weld mesh fence panels.
Specification
Specification of Razor Wire Mesh: BTO-10, BTO-15, BTO-22, BTO-25, BTO-28, BTO-65, Arrow Blades, Concertina Spectrum, H Type, Super H Type
